Fork-type Lifter
【Product Name】:
Fork-type Lifter
【Specification】:
WSL-2
【Applications】：
It is suitable for the horizontal flipping and lifting of bulk materials in pharmaceutical, chemical industries, especially suitable for the charging without leakage in the glove box and isolator.
Product Introduction
Technical Parameters:
Max. lifting height H: 2000mm
Min. height h: 300mm (the center of drum)
Max. load W: 150Kg (drum + materials)
Drum diameter D: 500mm
Axis misalignment K: 104mm
Width B: 1122mm
Length L: <105mm
Max. diagonal length: 1220mm
Features:
Mobile structure;
Fixed with the isolator;
Automatic docking, discharging inside the isolator;
Connecting to compressed air;
Special equipment, no adjustment.
